Overview
The Robinson R22/R44 series type-training course includes both theoretical and practical elements for the Airframe and the Power plant.
The course covers the general maintenance and repair of the R22 & R44 helicopters. A thorough review and explanation of the R22 & R44 Maintenance Manuals are provided with emphasis on routine maintenance and repair.
Detailed description, operation, component location, removal, installation and troubleshooting to maintenance manual level.
The course complies with “type training up to and including level 3” as stated in Part 66 Appendix 111 and the course syllabus can be found below.
Language
Courses are taught in English only.
Course objectives
In addition to the information contained in Level 1 and 2 training, at the completion of level 3, the engineer will be able to:
- Demonstrate a theoretical knowledge of aircraft systems and structures and interrelationships with other systems, provide a detailed description of the subject using theoretical fundamentals and specific examples and to interpret results from various sources and measurements and apply corrective action where appropriate.
- Perform system, engine, component and functional checks as specified in the maintenance manual.
- Demonstrate the use, interpret and apply appropriate documentation including structural repair manual, troubleshooting manual, etc.
- Correlate information for the purpose of making decisions in respect of fault diagnosis and rectification to maintenance manual level.
- Describe procedures for replacement of components unique to aircraft type.
On completion of the theoretical and practical training course the student shall be able to demonstrate, to the levels identified in the Appendix III syllabus, the detailed theoretical knowledge of the aircraft applicable systems, structures, operations, maintenance, repair and troubleshooting according to approved maintenance data. The student shall be able to demonstrate the use of manuals, special tooling and equipment and approved procedures, including the knowledge of relevant inspections and limitations.
Course examination
Examination will take place at the end of the Type training course.
- The type training examination standard is to PART 66 Appendix 111 “Type Training and examination Standard”.
- The post course examination is of the multiple-choice type format.
- The examination is of the closed book type, where no reference material is permitted.
- The examination pass mark is 75%.
- There is no penalty marking.
As well as a minimum 75% examination pass mark, a 90% course attendance has also to be obtained before the student is issued with a Certificate of Recognition.
Duration – 15 days in total
Theoretical element (days 1-10):
The total theoretical instructional hours will be 60 hours over a 10 working day period. The course days have a total of 6 hours of instruction with 3 hours of instruction given in the morning and 3 hours of instruction given in the afternoon; this does not include tea or lunch breaks, revision, aircraft walk around or the examination.
The theoretical course schedule below breaks the course in to modules/chapters taught by day number and morning and afternoon periods. A day's instruction commences at 08:30 and is complete by 16:10. It is recommended that students should arrive at least 15 minutes early each morning. A day is sectioned into the following periods:
- Period 1 is from 08:30 to 10:00
- Period 2 is from 10:20 to 12:00
- Period 3 is from 13:00 to 14:30
- Period 4 is from 14:50 to 16:10
Practical element (days 11-15):
The total practical instructional hours will be 30 hours over a 5 working day period. The course days have a total of 6 hours of instruction, with 3 hours of instruction given in the morning and 3 hours of instruction given in the afternoon; this does not include tea or lunch breaks, revision, or the examination.
Location
Sloane Helicopters, Sywell Aerodrome, Northampton, UK
Theoretical syllabus (days 1-10)
The total theoretical instructional hours will be 60 hours over a 10 working day period.
| Chapter of manual | Helicopter Piston B1 Level Mechanical | Time |
|---|---|---|
| General overview Introduction to the Robinson R22& R44 series |
Level 1 | Morning |
| 05. Time limits/components maintenance checks | Level 1 | Morning |
| 06. General aircraft (dimensions/weights, mtow etc) | Level 1 | Morning |
| 07. Lifting & Shoring | Level 1 | Afternoon |
| 08. Leveling & Weighing | Level 1 | Afternoon |
| 09. Towing & Taxing | Level 1 | Afternoon |
| Chapter of manual | Helicopter Piston B1 Level Mechanical | Time |
|---|---|---|
| 10. Parking/mooring, Storing & Returning to Service | Level 1 | Morning |
| 11. Placards & Markings | Level 1 | Morning |
| 12. Servicing | Level 1 | Morning & afternoon |
| 20. Standard practices | Level 1 | Afternoon |
| Helicopters | ||
| 18. Vibration & noise analysis (blade tracking) | Level 3 | Afternoon |
| 60. Standard practice - rotor | Level 3 | Afternoon |
| Zonal and station identification systems | Level 3 | Afternoon |
| Subject | Helicopter Piston B1 Level Mechanical | Time |
|---|---|---|
| Continued from Day 2 62a. Rotors – monitoring & indicating |
Level 3 | Morning |
| 63. Rotor drives | Level 3 | Morning |
| 63a. Rotor drives – monitoring indicating | Level 3 | Afternoon |
| Subject | Helicopter Piston B1 Level Mechanical | Time |
|---|---|---|
| 64. Tail rotor | Level 3 | Morning & afternoon |
| 65. Tail rotor drive | Level 3 | Morning |
| 67. Rotor flight control | Level 3 | Afternoon |
| 53. Airframe structure (helicopter) | Level 3 | Morning |
| Subject | Helicopter Piston B1 Level Mechanical | Time |
|---|---|---|
| Continued from Day 4 67. Rotor flight control |
Level 3 | Morning |
| 25. Emergency floatation equipment | Level 3 | Morning |
| Airframe systems | Level 3 | |
| 21. Air conditioning | Level 3 | Morning |
| 21a. Air supply | Level 3 | Morning |
| 21c. Safety & warning devices | Level 3 | Morning |
| 23. Communications | Level 2 | Afternoon |
| 24. Electrical power | Level 3 | Afternoon |
| 25. Equipment & furnishings | Level 3 | Afternoon |
| 25a. Electronic equipment inc’ emergency equipment | Level 1 | Afternoon |
| 26. Fire protection | Level 3 | Afternoon |
| Subject | Helicopter Piston B1 Level Mechanical | Time |
|---|---|---|
| 27. Flight controls | Level 3 | Morning & afternoon |
| 28. Fuel systems | Level 3 | Afternoon |
| Subject | Helicopter Piston B1 Level Mechanical | Time |
|---|---|---|
| 28a. Fuel systems – monitoring & indicating | Level 3 | Morning |
| 32. Landing gear | Level 3 | Morning |
| 52. Doors & windows | Level 3 | Morning |
| Piston engine | ||
| 70. Standard practices | Level 3 | Morning |
| 70a. Constructional arrangement etc. | Level 3 | Morning & afternoon |
| Subject | Helicopter Piston B1 Level Mechanical | Time |
|---|---|---|
| Continued from Day 7 70a. Constructional arrangement etc. |
Level 3 | Morning |
| 70b. Engine performance | Level 3 | Morning |
| 71. Power plant | Level 3 | Morning & afternoon |
| 73. Engine fuel & control | Level 3 | Afternoon |
| Subject | Helicopter Piston B1 Level Mechanical | Time |
|---|---|---|
| 76. Engine control | Level 3 | Morning |
| 79. Oil | Level 3 | Afternoon |
| Subject | Helicopter Piston B1 Level Mechanical | Time |
|---|---|---|
| 80. Starting | Level 3 | Morning & afternoon |
| 83. Accessory gear boxes | Level 3 | Afternoon |
Practical syllabus (days 11-15)
The total practical instructional hours will be 30 hours over a 5 working day period.
